APSX RW-110 RFID reader/writer supports read/write functionality for ISO15693 RFID tags with an operating frequency of 13.56MHz.

• 13.56MHz
• 19200 bps Data Rate
• Read/Write Range 4”
• Dimensions: (1 7/8"x1 1/8”x0.25”)
• On-board antenna
• Built-in TTL.
• Power consumption 20mA at stand-by, 50mA in fast mode (20 reads per sec.) under regulated 5V
• Powerful firmware enables read and write of any type 13.56 MHz RFID Tag (ISO15693)
• One programmable LED is available for visual feedback
• Requires a clean regulated 5VDC supply
• Simple modifications are necessary when used with C-100

     $49.95
   You will be directed to APSX Online Store

We meet all your needs in terms of space and read/write range requirements. We have three different products that operate under the same logic and infrastructure. The only difference among them is read/write range & size.

For projects that require a reasonable read/write range and minimal space, we have RW-110. RW-110 has 4" read/write range and around a 2 sq-in size which are the best values in the ISO15693 13.56MHz RFID market.

If your need is a longer distance around 11", the RW-310 designed just for that purpose. If you have ample space in your project design, the RW-310 is the perfect fit for your need.

If your needs are between those two cases above, we have RW-210. It provides the superior read/write range around 7" with its 12 sq-in size.

All three products can be tested and used with our APSX RFID Test Application (ARTA) which is available in our support pages and can be downloaded free of charge.

APSX OFFERINGS:

RFID Reader/Writers

There are three types of reader/writer:
RW-110, RW-210 and RW-310. They utilize ISO15693 read/write support for 13.56MHz RFID tag types. For serial connections, a level converter module, C-100, is available (Sold Separately).

WHERE TO BUY:

Wire Connections

To connect the reader to your system, follow these guidelines for the wire connections:

Pin 1: Ground
Pin 2 & 3: Not Used
Pin 4: 5V (Regulated)
Pin 5: TX (Serial Transmit)
Pin 6: RC (Serial Receive)
Pin 7: Ground
Pin 8: Not Used

Try our test application to see how RFID works. The standard ISO15693 functions are all available to test. APSX 13.56MHz RFID reader/writers,  which are designed and manufactured by APSX, provide premium performance in read/write range and power consumption. With the C-100 TTL to RS232 converter, APSX RFID reader/writers can be connected to a PC.
